NODZSIN-4-2-20 - Zigbee 2-Channel 2x 3 A Relay Switch SIN-4-2-20
Deliverytime: 1 - 3 working days (Mo-Fr) *
available: > 75
Key points at a glance:
Product Description
NODZSIN-4-2-20 - NodOn Zigbee 2-Channel 2x 3 A Relay Switch SIN-4-2-20
With its two channels, the NodOn Zigbee 2-channel 2x 3 A relay switch SIN-4-2-20 enables the user to connect and remotely control one or two lights via smartphone, by voice or automatically. It is easy to install, without building work, behind a wired wall switch, on the ceiling or in the electrical panel.
Please note: Requires a Zigbee compatible home automation system.
Features:
- Zigbee 2-channel 2x 3 A relay switch
- Compatible with lots of Zigbee ecosystems: Zigbee 3.0, this relay switch is 100% Zigbee interoperable
- Multiple installation options: At the ceiling light, behind an existing wired switch, without a wired switch; The installation of the relay switch is simple and quick
- Zero-crossing: The zero-crossing feature allows the relay switch to be fully compatible with all types of lamps
- Energy measurement: No
- Ultra low profile: Installation in electrical boxes from >30 mm
- Installation without DIY work: On the existing controller or at the electrical panel (DIN rail box needed)
- Update Over-The-Air (OTA): The relay switch is quick to update thanks to the OTA function
- Updates can be carried out via a compatible home automation system
Specifications
- Power supply: 230 V AC ~ 50 Hz
- Switching capabilities: 230 V AC - 2x 3 A
- Consumption: <1 W
- Maximum engine power: 2x 690 W - zero crossing
- RF protocol: Zigbee 3.0
- Wireless frequency range: 2.4 GHz
- RF power max.: +10 dBm
- Range: Up to 30 m indoors
- Operational temperature: -20°C to 60°C
- Protection rating: IP 20
- Device ID type: On/off Light (0x0100)
