NET-PWRCTRL HUT EX HV-P - High Voltage Extender, plug terminals
Deliverytime: 1 - 3 working days (Mo-Fr) *
available: 1
Product Description
ANEL-Elektronik NET-PwrCtrl HUT EX HV-P
High voltage Exeender with plug terminals, extends a NET-PwrCtrl HUT (2) by 8 more relays over the IOs.
Delivery contents:
- NET-PwrCtrl HUT EX HV-P
- IO cable
Specifications
- Relay: 8
- Input: 8
- Max. control (input) voltage: 12 V-
- Rated voltage power supply: 100 - 240 V~ 50 - 60 Hz
- Power consumption: 3 W
- Max. load each relay: 16 A/250 V~ (resistive load); 16 A/14-; TÜV R50126372
- Terminals I/O: AK4101
- Terminals relay: AK4101
- Terminals AK4101
- Connection cross sections
- Solid: 0,08 mm - 2,5 mm
- Stranded (flexible): 0,5mm - 1,5 mm
- Stranded with Ferrule: 0,14 mm - 1,0 mm
- Ratings: VDE 250 V 17,5 A; test voltage 2,0 kV
- Dimensions: L 106,5 x W 95 x H 63 mm; 6 fuses wide; 35 mm DIN rail
- Temperature range: -20°C to +60°C
- Humidity: 10 to 90% non-condensing
