E8 TAG BEACON (ACCEL. SENSOR) - MINEW E8 Tag Beacon with accelerometer sensor

Deliverytime: 1 - 3 working days (Mo-Fr) *
available: > 25
15,05 EUR
Key points at a glance:
Product Description

MINEW E8 Tag Beacon with accelerometer sensor

The Tag Beacon E8 is a new generation beacon that loaded a Bluetooth 5.0 hardware platform, low power consumption 3-axis accelerometer (optional) and MiniBeacon Plus intelligence software.

The E8 Tag Beacon advertises standard iBeacon, Eddystone (UID, URL, TLM) and accelerometer sensor data simultaneously. The user can configure the E8 Tag Beacon via configuration app BeaconSET+ as well.

Moreover, the E8 Tag Beacon with accelerometer advertises sensor data ONLY when an object is moving or after an object has fallen.


  • Advertising iBeacon & Eddystone & sensor data
  • Unique MAC address (ITU)
  • Bluetooth 5.0 chipset nRF52 series
  • Low power consumption 3-axis accelerometer
  • Includes 1pc. CR2032 coin battery replaceable
  • Max. 50 meters advertising distance
  • Weatherproof housing with key-chain hole
  • Case color: White
  • Battery model: 1x CR2032 coin battery, 3.0 V
  • Operation voltage: 1.8-3.6 V DC
  • Transmission current: 5.3 mA (peak current), tested at 0 dBm transmission power
  • Transmission range: 50 meters maximum
  • Sampling interval: 900 ms accelerometer
  • Sampling accuracy: +/-2 g default
  • Antenna: 50 Ohm on board PCB antenna
  • Size: 32 x 23 x 3.3 mm
File type: pdf | File size: 513.65KB
