Die Netzwerksicherheits-Appliances von Moxa schützen Ihre kritischen Industrieanlagen vor industriellen Cybersecurity-Bedrohungen mit integrierten OT-IT-Cybersecurity-Technologien wie OT-zentrischer Deep Packet Inspection (DPI) und Intrusion Prevention System (IPS).

Input/Output Interface
– Buttons: Reset button

Ethernet Interface
– 10/100/1000BaseT(X) Ports (RJ45 connector): 2
– Standards
IEEE 802.3 for 10BaseT
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3u for 100BaseT(X)

LED Interface
– LED Indicators: PWR1, PWR2, MANAGED, IPS/IDS, USB/F, BYPASS, 10/100/1000M

DoS and DDoS Protection
– Technology: ICMP Flood, IGMP Flood, UDP Flood, TCP SYN Flood, TCP Port SYN Scan, TCP Port FIN Scan, TCP Port NULL Scan, TCP Port Xmas Scan, UDP Port Scan

Firewall
– IPS Throughput: > 200 Mbps
– Latency: < 500 microseconds
– Deep Packet Inspection
Modbus TCP
Modbus UDP
CIP
EtherNet/IP
PROFINET-DCP
SLMP
Omron FINS
Siemens S7 Comm.
Siemens S7 Comm. Plus
MELSOFT
SECS/GEM
TOYOPUC
IEC 61850-MMS
Additional protocols will be supported through future firmware updates.
– Policy Enforcement Rules: 512 rules
– ICS Protocol Filter Profiles: 32 profiles
– Concurrent Connections (TCP): 30,000
– Automatic Pattern Updates via SDC
Pro Models: Supported (1 year of updates included)
Pro-H Models: Supported (requires IEC pattern update license)
SA Models: Not supported
– Manual Pattern Updates
Pro Models: Supported (1 year of updates included)
Pro-H Models: Supported (requires IEC pattern update license)
SA Models: Supported

Management
– Supported Interfaces: Web GUI and Security Dashboard Console

Real-Time Firewall/VPN Event Log
– Event Type: Cybersecurity, Policy enforcement, Protocol Filter, Assets detection, System event
– Media: Local storage, Syslog server

Serial Interface
– Console Port: USB Type-C

Power Parameters
– Connection: Removable terminal block
– Input Current: 0.605 A @ 12 VDC, 0.297 A @ 24 VDC, 0.143 A @ 48 VDC

Physical Characteristics
– Housing: Metal
– Dimensions: 40 x 70 x 83 mm (1.58 x 2.76 x 3.27 in)
– Weight: 322 g (0.71 lb)
– Installation: DIN-rail mounting, Wall mounting (with optional kit)

Enviromental Limits
– Operating Temperature
Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
– Storage Temperature: -40 to 85°C (-40 to 185°F)
– Ambient Relative Humidity: 5 to 95% (non-condensing)

Standards and Certification
– Safety: UL 60950-1 Ed.2, UL 62368-1
– EMC: EN 55032/35
– EMI: CISPR 32, FCC Part 15B Class A
– EMS
IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 0.5 kV; Signal: 1 kV
IEC 61000-4-6 CS: 3 V
IEC 61000-4-8 PFMF
– Hazardous Locations: UL/cUL Class I Division 2 Groups A/B/C/D
– Railway: EN 50121-4
– Traffic Control: NEMA TS2
– Shock: IEC 60068-2-27
– Freefall: IEC 60068-2-32
– Vibration: IEC 60068-2-6

MTBF
– Time: 1,340,000 hrs
– Standards: Telcordia (Bellcore), GB
