AOLS1 - QuOmni LTE SISO - Antenna omnidirectional multiband LTE SISO, 5m cable, SMA
Deliverytime: 16 - 18 working days (Mo-Fr) *
Product Description
QuOmni LTE SISO - Antenna omnidirectional multiband LTE SISO, 5m cable, SMA
QuOmni LTE omnidirectional SISO LTE antenna is working in Vertical polarization, its desired for LTE/3G/2G connections. The antenna can be used for the most popular LTE bands (e.g. 3,7,20), frequencies 694-2700 MHz. That antenna is predicted to be installed on the buildings (on the pole or on the wall) as the client antenna or on the moving points like trains, buses, lorries, yachts, boats to receive Internet by LTE/3G. Its compatible with Teltonika: RUT230, TRB140, TRB141, TRB142, TRB145, TRM240, TRM250 and other SISO LTE/3G/2G modems and routers.
Specifications
LTE ANTENNA SPECIFICATION
- Frequency: 0.694 - 0.96 GHz / 1.7 - 2.2 GHz / 2.2 - 2.7 GHz
- Supported LTE bands: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 15, 16, 17, 18, 19, 20, 23, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 44, 53, 65, 66, 67, 68, 69, 70, 71, 85
- Gain: 0.694 - 0.96 GHz : 2 dBi / 1.7 - 2.2 GHz : 2 dBi / 2.2 - 2.7 GHz : 4 dBi
- VSWR: <1.60, max <2.00
- Beamwidth: 360°/35° +/-5°
- Polarization: Vertical
- Impedance: 50 ohms
MECHANICAL SPECIFICATION
- Materials: ABS, aluminum, PTFE
- Ingress protection: IP67
- Dimensions: 160 x 160 x 240 mm
- Weight: 1.5 kg
- Operating temperature: From -40°C to 75°C / From -40°F to 167°F
