RUTX50000000 - Industrial 5G Router

Deliverytime: 1 - 3 working days (Mo-Fr) *
available: > 25
632,09 EUR
Product Description

RUTX50 - Industrial 5G Router

RUTX50 is your future-proof, multi-network industrial router, offering 5G mobile communication for high-speed and data-heavy applications.

5G dual SIM cellular communication combined with 5 Gigabit Ethernet ports and dual-band Wi-Fi enables reliable ultra-low latency data transfer.

The power of 5G technology, combined with a wide range of interfaces and industrial hardware features, ensures adaptability for future upgrades and expansions.

RUTX50 comes with the RutOS, which provides advanced security features and specialized industrial protocols for a wide range of professional application scenarios, and is compatible with Remote Management System (RMS), for optimized remote management and monitoring capabilities of large fleets of devices.



  • Mobile: 5G Sub-6 Ghz SA/NSA 2.1/3.3 Gbps DL (4x4 MIMO), 900/600 Mbps UL (2x2); 4G (LTE) – LTE Cat 20 2.0 Gbps DL, 200 Mbps UL; 3G – 42 Mbps DL, 5.76 Mbps UL
  • CPU: Quad-core ARM Cortex A7, 717 MHz
  • Flash storage: 256 MB
  • RAM: 256 MB
  • Powering options: 4-pin power socket, 9-50 V DC
  • SIM: 2x SIM slot (Mini SIM – 2FF), 1.8 V/3 V
  • Antenna connectors: 4x SMA for Mobile, 2x RP-SMA for WiFi, 1x SMA for GNSS
  • Ethernet: 5x 10/100/1000 Ethernet ports: 1x WAN (configurable as LAN), 4x LAN
  • WiFi: 802.11b/g/n/ac Wave 2 (WiFi 5) with data transmission rates of up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA)
  • Wireless mesh/roaming: Wireless mesh (802.11s), fast roaming (802.11r)
  • GNSS: GPS, GLONASS, BeiDou, Galileo, QZSS
  • Inputs/outputs: On 4-pin socket: 1x digital input, 1x digital open collector output
  • Other: 1x USB host, 1x grounding screw
  • Status LEDs: 3x connection status LEDs, 3x connection strength LEDs, 10x Ethernet port status LEDs, 4x WAN status LEDs, 1x Power LED, 2x 2.4G and 5G WiFi LEDs
  • Operating temperature: -40°C to 75°C
  • Housing: Aluminum housing, DIN rail (can be mounted on two sides), flat surface placement
  • Dimensions (W x H x D): 132 x 44.2 x 95.1 mm
  • Weight: 533 g


  • Operating system: RutOS (OpenWrt based Linux OS)
  • Mobile features: Multiple PDN, Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits
  • Network features: Routing, Failover, Firewall, DHCP, DDNS, Load Balancing, VoIP passthrough, Connection monitoring
  • Monitoring and Management: WEB UI, CLI, SSH, CALL, SMS, TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS
  • VPN and tunneling: OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, WireGuard, ZeroTier
  • Cloud solutions: RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
  • Hotspot: External/Internal Radius, SMS OTP, MAC authentication, Walled Garden
  • GNSS: NMEA forwarding, AVL, Geofencing
File type: pdf | File size: 1.14MB
