AF-3G26-S45 - airFiber Antenna

Deliverytime: 1 - 3 working days (Mo-Fr) *
available: < 10
271,11 EUR
Product Description

airFiber Antenna AF-3G26-S45

Pair an airFiber X antenna with an airFiber X radio to create the endpoint of a high-performance, Point-to-Point (PtP) bridge or network backhaul (airFiber X radio sold separately).

Powerful Performance
The airFiber X antenna delivers 2x2 dual-polarity performance. In the manual on the left is one example of how the airFiber X antenna with an airFiber X radio can be deployed in a backhaul link to deliver bandwidth from an ISP network out to a neighborhood tower. From there, an airMAX Sector antenna with a Rocket(TM) radio delivers bandwidth to the ISPs customers.

Carrier-Class Construction
Incorporating a dish reflector design for excellent beam directivity, the airFiber X antennas feature robust mechanical design using industrial-strength hardware for outdoor application use.

Plug and Play Integration

airFiber X antennas and airFiber X radios have been designed to seamlessly work together. Every airFiber X antenna has a built-in airFiber X radio mount, so installation requires no special tools. Snap the airFiber X radio securely into place and mount the antenna; you then have the optimal combination of airFiber X antenna and airFiber X radio for your PtP application

Hardware Overview
Innovative Mechanical Design

  • Secure Pole-Mounting: The hardware is designed to securely mount and maintain the position of the dish during harsh outdoor conditions.
  • Convenient Installation: The bubble level allows for easy alignment.
  • Precision Elevation Adjustment: Use this new feature to quickly fine-tune and adjust the elevation.

Weatherproof Design

  • Protective Shroud: The shroud protects the cables and connectors from natures elements.
  • Mounting Hardware: Made of galvanized steel that is powder-coated for superior corrosion resistance.
  • Fasteners: GEOMET-coated for improved corrosion resistance when compared with
  • Model: AF-3G26-S45
  • Dimensions: 650 x 300 mm ( 25.59 x 11.81")
  • Weight: 9.8 kg (21.61 lb)
  • Frequency Range: 3.3 - 3.8 GHz
  • Gain: 26 dBi
  • + 45° Beamwidth: 7° (3 dB)
  • - 45° Beamwidth: 7° (3 dB)
  • F/B Ratio: 33 dB
  • Max. VSWR: 1.4:1
  • Wind Loading: 787 N (at) 200 km/h (177 lbf (at)125 mph)
  • Wind Survivability: 787 N (at) 200 km/h (177 lbf (at)125 mph)
  • Polarization: Dual-Linear
  • Cross-pol Isolation: 35 dB Min.
  • ETSI Specification: EN 302 326 DN2
  • Mounting: Universal Pole Mount, airFiber X Radio Bracket, and Weatherproof RF Connectors Included
File type: pdf | File size: 4.45MB
