Teltonika FMM001 represents the next step in communication technology – this is the first Plug-and-Track LTE Cat. M1 OBD device with GNSS and Bluetooth connectivity. Possibility to read OBD II parameters, effortless installation and detailed accelerometer data provides a compelling solution. This is perfect tracker for a wide range of applications – fleet management of light commercial vehicles, car rental & leasing, driver log-book, insurance telematics (UBI) and so on. The device supports various Bluetooth Low Energy sensors, beacons, as well as firmware and configuration updates via Bluetooth.

Specifications

Module

Name: Quectel BG96, Teltonika TM2500
Technology: LTE Cat. M1/CAT NB1/EGPRS/GNSS/Bluetooth

GNSS

GNSS: GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS
Receiver: 33 channels
Tracking sensitivity: -165 dBM
Accuracy: < 2.5 m CEP
Hot start: < 1 s
Warm start: < 25 s
Cold start: < 35 s

Cellular

Technology: LTE Cat. M1/Cat. NB1/EGPRS
2G bands: Quad-band 800/850/900/1900 MHz
4G bands: LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B28; LTE TDD: B39 (for Cat. M1 only)
Data transfer: Cat. M1: Max. 375 Kbps (DL), max. 375 Kbps (UL); Cat. NB1: Max. 32 Kbps (DL), max. 70 Kbps (UL); GPRS: Max. 107 Kbps (DL), max. 85.6 Kbps (UL)
Data support: SMS (text/data)

Power

Input voltage range: 10 - 30 V DC with overvoltage protection
Internal back-up battery: 170 mAh Li-Ion battery 3.7 V (0.63 Wh)

Bluetooth

Specification: 4.0 + LE
Supported peripherals: Temperature and humidity sensor, Inateck barcode scanner, universal BLE sensors support

Physical Specification

Dimensions: 67,2 x 49,6 x 25 mm (L x W x H)
Weight: 63 g

OBD Interface

Data: K-Line, CAN bus data
Data reading: Up to 32 vehicle onboard parameters, supported OBD protocols: SAE J1850 PWM (41.6 kbaud); SAE J1850 VPW (10.4 kbaud); ISO 9141-2 (5 baud init, 10.4 kbaud); ISO 14230-4 KWP (5 baud init, 10.4 kbaud); ISO 14230-4 KWP (fast init, 10.4 kbaud); ISO 15765-4 CAN (11 bit ID, 250 kbaud); ISO 15765-4 CAN (11 bit ID, 500 kbaud); ISO 15765-4 CAN (29 bit ID, 250 kbaud); ISO 15765-4 CAN (29 bit ID, 500 kbaud)

Interface

Connection: OBDII socket
GNSS antenna: Internal high gain
Cellular antenna: Internal high gain
USB: 2.0 Micro-USB
LED indication: 2 status LED lights
SIM: Micro-SIM
Memory: 128 MB internal flash memory

Operating Environment

Operating temperature (without battery): -40°C to +85°C
Storage temperature (without battery): -40°C to +85°C
Operating humidity: 5% to 95% non-condensing
Ingress protection rating: IP41
Battery charge temperature: 0°C to +45°C
Battery discharge temperature: -20°C to +60°C
Battery storage temperature: -20°C to +45°C for 1 month; -20°C to +35°C for 6 months

Features

Sensors: Accelerometer
Scenarios: Green driving, over speeding detection, GNSS fuel counter, excessive idling detection, unplug detection, towing detection, crash detection, auto geofence, manual geofence, trip
Sleep modes: GPS sleep, online deep sleep, deep sleep, ultra deep sleep
Configuration and firmware update: FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (configuration)
SMS: Configuration, events, debug
GPRS commands: Configuration, debug
Time synchronization: GPS, NITZ, NTP
Fuel monitoring: OBD II
Ignition detection: Accelerometer, external power voltage, engine RPM
