MINEW E9 Dear Beacon

The Dear Beacon E9 is a new generation beacon that loaded a Bluetooth 5.0 hardware platform and MiniBeacon Plus intelligence software. The E9 Dear Beacon has a smart rotatable mechanical design for a replaceable coin battery and an IP67-grade waterproof housing. Moreover, the E9 Dear Beacon can be fixed using two screws or adhesive tape.

The E9 Dear Beacon advertises standard iBeacon and Eddystone (UID, URL, TLM) data packet simultaneously. The user can configure the E9 Dear Beacon via configuration app BeaconSET+ as well.


  • IP67 waterproof
  • Replaceable coin battery 1000 mAh
  • Advertising iBeacon & Eddystone
  • Unique MAC address (ITU)
  • Bluetooth 5.0 chipset nRF52 series
  • Max. 100 meters advertising distance
  • Internal power ON/OFF push button
  • Tough enclosure and screw fixing
  • Case color: Black
  • Battery model: 1x CR2477 3.0 V, 1000 mAh
  • Operation voltage: 1.8-3.9 V DC
  • Transmission current: 5.3 mA (peak current), tested at 0 dBm transmission power
  • Transmission range: 100 meters maximum
  • Waterproof level: IP67 tested at 1 meter water depth
  • Antenna: 50 ohm on board PCB antenna
  • Size: 49 mm diameter, 66 mm length, 17.5 mm height
