BPI-M1+ - Banana Pi - Dual-Core Single Board Computer, Wi-Fi

Deliverytime: 1 - 3 working days (Mo-Fr) *
available: > 10
56,89 EUR
Available options:
Power supplies
Product Description

Banana Pi BPI-M1+ - Dual-Core Single Board Computer, Wi-Fi

Banana Pi is an open source hardware platform. The Banana Pi model BPI-M1+ has a dual-core processor and runs Android, Debian Linux, Ubuntu Linux, as well as the Raspberry Pi and cubieboard image.

The boards hardware include: 1 GHz ARM7 dual-core processor, 1 GB DDR3 SDRAM, SDIO Wi-Fi module on board, 1x Gigabit Ethernet port and 1x SATA Socket. It can run smoothly with Android 4.2.2. The size of the board is about the size of a credit card.

It can easily run games as it supports 1080P high definition video output. The GPIO is compatible with Raspberry Pi and can run Raspbian image directly.

Specifications
  • CPU: A20 ARM Cortex(TM)-A7 dual-core
  • GPU: ARM Mali400MP2, complies with OpenGL ES 2.0/1.1
  • Memory (SDRAM): 1 GB DDR3 (shared with GPU)
  • Low-level peripherals: 40 pins header, 28x GPIO, some of which can be used for specific functions including UART, I2C, SPI, CAN, ADC, PWM, etc.
  • Wi-Fi module: Wi-Fi 802.11b/g/n (AP6181 module on board)
  • Bluetooth: optional
  • Onboard storage: MicroSD (TF) card, SATA 2.0
  • Onboard network: 10/100/1000 Ethernet (Realtek RTL8211E/D)
  • Display: Supports multi-channel HD display:
    • HDMI 1.4 (type A - full)
    • LVDS/RGB/CPU display interface (DSI) for raw LCD panels
    • Composite video (PAL and NTSC, via 3.5 TRRS jack shared with audio output)
    • 11 HDMI resolutions from 640x480 to 1920x1080 plus various PAL and NTSC standards
  • Video:
    • HD H.264 2160p video decoding
    • Multi-format FHD video decoding, including Mpeg1/2, Mpeg4, H.263, H.264 etc.
    • H.264 high-profile 1080p (at) 30 fps or 720p (at) 60 fps encoding
  • Audio output: HDMI, analog audio (via 3.5 mm TRRS jack shared with composite video out, I2S audio (also potentially for audio input)
  • Camera: Parallel 8-bit camera interface
  • Audio input: On board microphone
  • Power source: 5 Volt via MicroUSB (DC In only) and/or MicroUSB (OTG)
  • USB: 2 USB 2.0 ports, 1 USB 2.0 OTG (all directly from A20 chip)
  • Buttons: Reset button, power button, u-boot button
  • LED: Power status (red), user-defined 1 (green), user-defined 2 (blue)
  • Other: IR receiver
  • Product size: 92 x 60 mm
  • Weight: 45 g
