MINEW G1 - Bluetooth 5.0 WiFi Gateway

Deliverytime: 1 - 3 working days (Mo-Fr) *
available: < 10
98,05 EUR
Key points at a glance:
Product Description

MINEW G1 - Bluetooth 5.0 WiFi Gateway

Minew G1 is a Bluetooth 5.0 low energy (BLE) to Wi-Fi/Ethernet connectivity gateway without the use of smartphones or apps. The G1 gateway collects the data from iBeacon, Eddystone, BLE sensors and other BLE devices and sends it to the local server or remote cloud server by MQTT/MQTT over SSL/TLS /HTTP/HTTPS protocol via Wi-Fi/Ethernet/external 3G/4G USB dongle.

The user can easily configure the G1 gateway via a very simple web UI. It also supports batch configuration.

Specifications

General:

  • Connect to the Cloud with 3G/4G USB dongle
  • Data saved in TF data card or Udisk
  • Supports AWS/Azure/ARM mBed Iot Cloud
  • Input with DC 5.0 V, 1 A, Micro-USB
  • Firmware upgraded by OTA
  • Supports HTTP(SSL/TLS)/MQTT(SSL/TLS & Proxy)/TCP
  • Operating temperature: -25°C to 65°C
  • Batch configuration tool available

WiFi & Ethernet:

  • CPU 575 MHz 32-bit application processor
  • 300 Mbps PHY data rate, 802.11b/g/n WiFi
  • 2x USB 2.0 host connectors and 1x TF card slot
  • 128 Mbyte 16-bit DDR2 RAM
  • 16 Mbyte SPI NOR Flash
  • RGB LED strip as status indicator
  • OpenWrt, Linux distribution for embedded devices
  • Supports WiFi failover & Multi-Higher Level AP configuration
  • 10/100 Ethernet with 802.3af PoE

Bluetooth Low Energy:

  • 64 MHz 32-bit processor
  • Built-in power amplifier chip to precisely scan BLE
  • At least Bluetooth 4.0 (only for BLE)
