This docking station by Delock can be connected to a computer with USB-C™ DP Alt Mode or Thunderbolt™ 3 or Thunderbolt™ 4Portand provides a variety of interfaces. A monitor with a maximum resolution of up to 4Kcan be operatedat the HDMI output. Two integrated USB Type-A and one USB-C™ port enablethe use of peripheral devices.

Integrated 10/100/1000 Mbps LAN connection In addition, the docking station with integrated RJ45 Gigabit LAN connectionadds a network interface to a PC or notebook.

USB Power Delivery (USB PD 3.0) support up to 90 watts

The docking station has a USB Type-C™ Power Delivery port. If this port is connected to the power supply unit of the notebook or tablet, the host device is chargedwith up to 90 wattsduring operation.

Switches for each port
The Delock docking station has switches for each porton the top. This allows each port to be switched on or off individually, which is indicatedby an LED on the switch. This can be useful in a meeting, for example, if the monitor needs to be disconnected from the connected notebook for a short time.

Technical data

Connections:
– 1 x USB Type-C™ plug
– 2 x USB 5 Gbps Type-A socket
– 1 x USB 5 Gbps USB Type-C™ socket
– 1 x HDMI socket
– 1 x Gigabit LAN 10/100/1000 Mbps RJ45 socket
– 1 x USB Type-C™ PD socket (power supply)

– Resolution up to 3840 x 2160 @ 60 Hz (depending on system and connected hardware)
– Transmission of audio and video signals
– Supports HDCP 1.4 and 2.2
– Supports HDR
– Input power PD connection: 100 W, 10 W are used for the docking station
– Output power for host: max. 90 W
– 6 x LED display
– 6 x switch
– Metal housing
– Cable length without connections: approx. 28 cm
– Colour: midnight blue
– Dimensions (LxWxH): approx. 139 x 50 x 17 mm

System requirements:
– Android 14.0 or higher
– Chrome OS
– Linux Kernel 6.2 or higher
– Mac OS 14.2.1 or higher
– Windows 10/10-64/11
– iPad Air (4. Generation) or higher
– iPad Pro (3rd Generation) or higher
– iPhone 15 Pro or higher
– Surface Pro 7
– Device with a free USB Type-C™ port and DisplayPort Alternate Mode or with a free Thunderbolt™ 3 or Thunderbolt™ 4 port

Package contents
– USB-C™ docking station
– User manual
