Delock – 88749 – LTE antenna SMA 2 dBi 3 m RG-174 omnidirectional black outdoor

Brand:
Delock

28,04 €

incl. 19% VAT plus shipping costs

You can install this LTE antenna indoors or outdoors and use it for all the LTE bands mentioned. The antenna is fully compatible with GSM/ UMTS/ WLAN 2.4 GHz, ZigBee, Z-Wave and Bluetooth. LTE Band: 1-10; 12-20; 23; 25-30; 33-41; 44 Frequency ranges:…

Show article information
In stock
When you purchase this item you will receive. 28 Points
Bulk PriceQuantity (from)Quantity (to)
28,04 € 1 19
26,89 € 20 49
26,65 € 50 199
26,42 € 200 ∞
Delivery time: 3-5 Workdays
Add to quote request
SKU 357795
EAN 4043619887491
MPN 88749
Categories , ,
Tags , ,

You can install this LTE antenna indoors or outdoors and use it for all the LTE bands mentioned. The antenna is fully compatible with GSM/ UMTS/ WLAN 2.4 GHz, ZigBee, Z-Wave and Bluetooth.

  • LTE Band: 1-10; 12-20; 23; 25-30; 33-41; 44
  • Frequency ranges: 694 – 960 MHz, 1710 – 2700 Mhz
  • GSM: 710/750/810/850/1800/1900
  • P-GSM: 900
  • R-GSM: 900
  • T-GSM: 810/900
  • UMTS: Band I-X/XII-XIV/XIX
  • WLAN 2.4 GHz
  • ZigBee
  • Z-Wave
  • Bluetooth
  • DECT
  • Gain: 2 dBi
  • Polarisation: linear vertical
  • Impedance: 50 Ohm
  • VSWR:
    2.0 max. @ 694~960 MHz/ 1710~2170 MHz
    3,0 max. @ 2400~2700 MHz
  • Dimensions:
    Height: 48 mm
    Diameter: 50 mm
  • Screw-on mounting 12 mm central hole
  • Cable length: approx. 3 m
  • Cable type: RG-174
  • Cable attenuation: approx. 1 dB/m @ 1 GHz
  • Cable connection: SMA plug
  • Operating temperature: -10 °C ~ 55 °C
  • ABS UV protected
  • IP 67 RATING

Package contents

  • LTE antenna
  • Nut, washer
Weight 0,1 kg
Dimensions 15 × 10 × 10 cm
Transmission power

2dBi
Environment

outdoor
Connections

SMA
Antenna kind

GSM-Antenna, LTE Antenna, UMTS Antenna
Produkttyp

Antenne
antenna gain

2dBi
cable type

RG-174
Color

black
operating tempertur

-10°C - +55°C
Antenna type

Omni antennas
Frequency range

1.7- 2.7GHz, 700 - 960 MHz
Cable length

3m
