ALFA Network – AWM27921U – WiFi 6/ 6e 2×2 + Bluetooth 5.2 Wireless USB M.2 Module
incl. 19% VAT plus shipping costs
The WLAN subsystem contains the 802.11a/b/g/n/ac/ax radio, a baseband designed to meet feature-rich wireless connectivity at high standards, and deliver reliable, cost-effective throughput from an extended distance.Optimized RF architecture and…
SKU | 375152 |
---|---|
EAN | 4718050308859 |
MPN | AWM27921U |
Categories | Hardware, extensions, WLAN extensions |
Tags | Adapter, ALFA Network, Hardware, multicolor |
The WLAN subsystem contains the 802.11a/b/g/n/ac/ax radio, a baseband designed to meet feature-rich wireless connectivity at high standards, and deliver reliable, cost-effective throughput from an extended distance.
Optimized RF architecture and baseband algorithms provide superb performance and low power consumption. Intelligent MAC design deploys a highly efficient offload engine and hardware data processing accelerators which fully offloads WiFi task of the host processor.
Key features
• IEEE 802.11 a/b/g/n/ac/ax compliant
• Support 20 MHz, 40 MHz, 80 MHz bandwidth in 2.4 GHz, 5 GHz, 6GHz band
• Support Bluetooth 5.2
• Dual-band 2T2R mode
• Data rate up to 800 Mbps with USB3.0
• Support STBC, LDPC, TX Beamforming, and RX Beamforming
• Bluetooth v5.2 with BLE (BT low energy)
• Support BT/BLE dual mode
• Support BT/WiFi coexistence
Specifications
– Chipset: MediaTek MT7921AUN
– IEEE 802.11 standards: a/b/g/n/ac/ax
– Frequency: 2.4 GHz/ 5 GHz/ 6 GHz
– Bluetooth: v5.2
– Data Rate: 11b: 1, 2, 5.5, 11 Mbps
11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
11n: up to 300 Mbps
11ac: up to 866.7 Mbps
11ax: up to 573.5 Mbps
11ax: up to 1201 Mbps
– Form factor: M.2 (USB bus)
– Antenna connector: 2x IPEX (WiFi)/ 2x IPEX (BT)
– Dimensions: 30 x 42 x 4.12 mm
– Operating temperature: -25° C – 75° C
– Operation voltage: 3.3 V
– Power consumption: 755 mA (max.)
– Operating systems: Microsoft Windows (10/11)/ Linux
Weight | 0,1 kg |
---|---|
Dimensions | 5 × 4 × 3 cm |
Connections | M.2 |
Produkttyp | Adapter |
Color | multicolor |
